1000h V Fender High Compression Stable Performance Safe Fit Easy To Install
Description
Made from premium marine-grade rubber compounds, Arch Fenders are built to withstand harsh marine environments, including UV rays, saltwater, and temperature fluctuations. Their rugged construction ensures minimal wear over time, even under continuous heavy-duty use. With minimal maintenance requirements, these fenders provide reliable, long-term service and a high return on investment.
Specifications
Product Name |
Arch Rubber Fender |
|
Material |
Natural rubber, Silicone rubber |
|
Colour |
Black, or customized |
|
Surface |
Smooth |
|
Size |
Height |
200-1000mm |
Length |
1000-3500mm |
|
All sizes can be customized |
||
Physical Properties |
Polymer Content |
100% virgin |
Working temperature |
-50℃~240℃ |
|
Tensile strength |
≥16 mpa |
|
Density |
90+/-5 Per 100mm in |
|
Hardness |
50-70 (shore A) |
|
Elongation |
≥400% |
|
Features |
1. Through high temperature resistant |
|
2. Excellent tear resistant, oil resistant, aging resistant |
||
3. Resistant to industrial acid & alkali and good elastic |
||
4. Built as per PIANC2002 |
||
Application |
Multi-Purpose-Terminals, RoRo ramps, Passenger Vessel Terminals, Barge |
Model |
W |
B |
F |
C |
H |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
|
HM-ARF200H |
400 |
320 |
145 |
128 |
200 |
HM-ARF250H |
500 |
410 |
175 |
160 |
250 |
HM-ARF300H |
600 |
490 |
225 |
196 |
300 |
HM-ARF400H |
800 |
670 |
300 |
260 |
400 |
HM-ARF500H |
1000 |
840 |
375 |
325 |
500 |
HM-ARF600H |
1200 |
1010 |
450 |
390 |
600 |
HM-ARF800H |
1600 |
1340 |
600 |
520 |
800 |
HM-ARF1000H |
2000 |
1680 |
750 |
650 |
1000 |
Features
Excellent Shear Resistance
Built to handle lateral movement and dynamic shear forces caused by vessel drift or tidal variations without tearing or deformation.
Abrasion Resistant Surface
Outer surface is resistant to friction and wear from repeated vessel contact, especially under rough berthing conditions.
Compact and Robust Design
The simple arch profile provides outstanding performance in a compact structure, ideal for space-limited docking areas.
Wide Range of Sizes
Available in standard heights from 200mm to 1200mm (or more), allowing easy selection based on vessel type and dock height.
Applications
► Coastal piers
► Inland terminals
► Tugboat landings
► Workboat berths
Advantages
Long Term Customer Relationships
Many of our clients have worked with us for over a decade, a testament to our consistent product performance and service reliability.
OEM ODM Capability
We support private labeling and customized designs, enabling global partners to build their own fender brands with our manufacturing support.
Corrosion Resistant Mounting Hardware Available
We supply full fender systems, including galvanized or stainless-steel bolts, plates, and accessories for marine durability.
Fast Prototyping and Sample Production
For custom projects or tender requirements, we can produce samples within short lead times for client approval.
FAQ
1. What materials are Arch Rubber Fenders made from?
They are made of high-quality natural and synthetic rubber compounds, designed for durability, UV resistance, and marine environment tolerance.
2. How long is the typical service life of these fenders?
With proper maintenance, Arch Rubber Fenders can last 10 to 20 years or more in marine applications.
3. Are Arch Rubber Fenders suitable for all types of vessels?
Yes, they are versatile and used for ferries, cargo ships, tankers, naval vessels, and tugboats.
4 How are Arch Rubber Fenders installed?
They are typically bolt-mounted onto quay walls or fender panels using standard fixing brackets and hardware.
