Hongruntong Powerful Arch Rubber Fender For Protecting Ships Of All Sizes

1 Piece
MOQ
USD215 to USD910 Per Piece
Price
Hongruntong Powerful Arch Rubber Fender For Protecting Ships Of All Sizes
Features Gallery Product Description Request A Quote
Features
Specifications
Features: Arch Rubber Fender
Part: Dock Fixed Rubber Fender
Color: Black Or As Required
Material: Grade A Natural Rubber
Tensile Strength: ≥8 Mpa
Elongation: ≥300%
Hardness: 80±5 Shore A
Height: 100mm-3000mm
Length: 2000mm-5000mm
Packing: Pallet Packing, Bare Packing, Frame Packing
OEM: Warmly Welcomed
Certification: ABS,BV, LR, DNV, SGS, CCS, RMRS
Application: Port, Dock, Wharf, Etc
Accessory: Front Panel, Face Panel, Bolt, Nut, Etc
Highlight:

Powerful Arch-Section Fenders

,

Protecting Ships Arch-Section Fenders

,

Powerful Arch Shaped Fenders

Basic Infomation
Place of Origin: CHINA
Brand Name: Hongruntong Marine
Certification: DNV, LR, ABS, BV, SGS, RMRS, CCS
Model Number: HM-V200H
Payment & Shipping Terms
Packaging Details: Wooden pallet, Steel pallet, Wooden case
Delivery Time: 3-6 Work Days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 1810 Pieces Per Month
Product Description

HONGRUNTONG Powerful Arch Rubber Fender For Protecting Ships Of All Sizes



Description



The Arch Rubber Fender stands as a stalwart guardian of vessels navigating the turbulent waters of maritime berthing operations. Characterized by its distinctive arch shape, this specialized marine fender is engineered to mitigate the impact forces encountered during vessel mooring, ensuring the safety of both ship and port infrastructure. Crafted from premium-grade rubber compounds, Arch Rubber Fenders exhibit an exceptional ability to absorb kinetic energy, thereby minimizing the risk of damage caused by collisions. The arch design facilitates even force distribution, enhancing its efficacy in dispersing impact energy across a wider surface area.


Renowned for their durability and resilience, Arch Rubber Fenders withstand the harsh conditions of marine environments with unwavering reliability. They are adept at enduring prolonged exposure to saltwater, UV radiation, and fluctuating temperatures, ensuring long-term performance and minimal maintenance requirements. Installation of Arch Rubber Fenders is streamlined, allowing for swift deployment in ports, docks, and terminals worldwide.


These fenders play a pivotal role in safeguarding vessels of all sizes, from modest fishing boats to colossal container ships, against the perils of docking mishaps. Their versatility extends to various berthing scenarios, including alongside quays, piers, and jetties. The widespread adoption of Arch Rubber Fenders underscores their indispensable contribution to maritime safety and operational efficiency. As sentinels of the seas, they stand as a testament to the ingenuity of marine engineering, fortifying the bonds between vessels and the harbors they call home.



Hongruntong Powerful Arch Rubber Fender For Protecting Ships Of All Sizes 0





Specifications



Brand Name Hongruntong Marine
Model Number HM-V200H
Processing Service Moulding, Cutting
Keywords Arch Rubber Fender Type V
Color Black, Grey, White, or as request
Material Grade A Natural Rubber
Tensile Strength ≥8 Mpa
Elongation ≥300%
Hardness 70±5 Shore A
Height 100mm-3000mm
Length 2000mm-5000mm
Accessory Front Panel, Face Panel, Bolt, Nut, etc
Package Polybag, Pallet, Wooden Case
Usage Dock Boat Protection





Hongruntong Powerful Arch Rubber Fender For Protecting Ships Of All Sizes 1



Model Specifications (mm)
H L L1 C Q n B B1 B2 B3 h a b e f
DF-V150 x 1000L 150 1000 1075 110 855 2 98 240 300 96 25 50 95 25 55
DF-V150 x 2000L 150 2000 2075 107.5 620 4 98 240 300 96 25 50 95 25 55
DF-V150 x 3000L 150 3000 3075 107.5 715 5 98 240 300 96 25 50 95 25 55
DF-V200 x 1000L 200 1000 1100 120 860 1 135 320 400 128 30 58 105 29 75
DF-V200 x 2000L 200 2000 2100 120 620 3 135 320 400 128 30 58 105 29 75
DF-V200 x 3000L 200 3000 3100 120 715 4 135 320 400 128 30 58 105 29 75
DF-V250 x 1000L 250 1000 1125 130 865 1 164 410 500 160 33 64 125 32 90
DF-V250 x 2000L 250 2000 2125 132.5 620 3 164 410 500 160 33 64 125 32 90
DF-V250 x 3000L 250 3000 3125 132.5 715 4 164 410 500 160 33 64 125 32 90
DF-V300 x 1000L 300 1000 1150 140 870 1 225 490 600 195 33 70 140 35 105
DF-V300 x 2000L 300 2000 2150 137.5 625 3 225 490 600 195 33 70 140 35 105
DF-V300 x 3000L 300 3000 3150 145 715 4 225 490 600 195 33 70 140 35 105
DF-V400 x 1000L 400 1000 1200 150 900 1 300 670 800 260 40 82 165 41 120
DF-V400 x 2000L 400 2000 2200 147.5 635 3 300 670 800 260 40 82 165 41 120
DF-V400 x 3000L 400 3000 3200 150 725 4 300 670 800 260 40 82 165 41 120
DF-V500 x 1000L 500 1000 1250 160 930 1 375 840 1000 325 45 94 180 47 140
DF-V500 x 2000L 500 2000 2250 157.5 645 3 375 840 1000 325 45 94 180 47 140
DF-V500 x 3000L 500 3000 3250 156 730 4 375 840 1000 325 45 94 180 47 140
DF-V600 x 1000L 600 1000 1300 170 960 1 450 1010 1200 390 54 100 195 50 160
DF-V600 x 2000L 600 2000 2300 167.5 655 3 450 1010 1200 390 54 100 195 50 160
DF-V600 x 3000L 600 3000 3300 170 740 4 450 1010 1200 390 54 100 195 50 160
DF-V800 x 1000L 800 1000 1400 180 1040 1 600 1340 1600 520 72 136 270 68 260
DF-V800 x 2000L 800 2000 2400 180 680 3 600 1340 1600 520 72 136 270 68 260
DF-V800 x 3000L 800 3000 3400 180 760 4 600 1340 1600 520 72 136 270 68 260
DF-V1000 x 1500L 1000 1500 2000 200 800 2 750 1680 2000 650 90 136 290 68 300





Hongruntong Powerful Arch Rubber Fender For Protecting Ships Of All Sizes 2





Features



Superior Impact Absorption
Arch Rubber Fenders excel in absorbing and dissipating impact energy during berthing operations, minimizing the risk of damage to both vessels and port infrastructure. Their specialized design ensures effective protection against collisions, making them an indispensable asset for maritime safety.


Exceptional Durability
Crafted from premium-grade rubber compounds, Arch Rubber Fenders exhibit outstanding resilience and durability, capable of withstanding the harsh marine environment. Their robust construction ensures prolonged service life and reliable performance, even in challenging conditions.


Versatile Application
Arch Rubber Fenders are highly versatile, suitable for a wide range of berthing scenarios including quays, piers, and jetties. Their adaptability makes them a preferred choice for ports, docks, and terminals worldwide, offering reliable protection to vessels of all sizes and types.


Easy Installation and Maintenance
Designed for streamlined installation, Arch Rubber Fenders allow for swift deployment without compromising on performance. Additionally, their minimal maintenance requirements contribute to cost-effectiveness and operational efficiency, making them a practical and reliable solution for maritime infrastructure





Applications



● Ports
Marinas
Wharfs
Docks
Jetties





Advantages



Extensive Manufacturing Experience
With over 30 years of manufacturing experience, our factory has developed deep expertise in the production of arch fenders. This allows us to consistently deliver high-quality products that meet or exceed industry standards.


Customization Capabilities
Our factory understands that each project has unique requirements. We offer extensive customization options to tailor our arch fenders to specific customer needs, ensuring optimal performance and customer satisfaction.


Quality Materials and Construction
We use only the highest quality materials for our arch fenders, ensuring durability, longevity, and excellent performance. Our products are manufactured with precision and attention to detail, guaranteeing reliable operation and minimal maintenance requirements.


Technical Expertise and Support
Our team consists of highly skilled engineers and professionals who possess deep technical knowledge in the field of arch fender manufacturing. We provide technical support to our customers, offering guidance and advice throughout the entire project lifecycle, ensuring successful implementation.



Hongruntong Powerful Arch Rubber Fender For Protecting Ships Of All Sizes 3



Hongruntong Powerful Arch Rubber Fender For Protecting Ships Of All Sizes 4Hongruntong Powerful Arch Rubber Fender For Protecting Ships Of All Sizes 5
