Docking Fender Lightweight Anti Slip Surface Texture Easy Installation
Description
V Type Fenders are widely adopted in commercial ports, shipyards, and offshore platforms due to their durability and adaptability. Unlike solid rubber fenders, their hollow V-shape reduces weight while maintaining high energy absorption (up to 60 kJ/m²). They are particularly suited for container ships, Ro-Ro vessels, and barges, where low-maintenance and long service life (15+ years) are critical. Available in standard sizes (H300mm–H800mm) or custom profiles, they can be paired with anti-slip surfaces or reflective strips for safety. Their competitive pricing and global supply chain availability make them a preferred choice for emerging markets.
Specifications
| Product Name |
V Type Fender |
| Material |
High Performance Natural Rubber |
| Standard |
HGT2866-2016, PIANC2002 |
| Shape |
V Type |
| Feature |
Easy Replacement Firm for Installation |
| Part |
Dock Bumper |
| Usage |
Dock Port Wharf Boat Ship |
| Surface |
Matte/Smooth |
| Packing |
Pallet or Wooden Case |
| Keywords |
Arch Rubber Fender/V Rubber Fender |
| Model |
A |
D |
E |
F |
H |
K |
M |
R x Q |
Lmax |
| V Type |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
| HM-VTF150 |
50 |
240 |
326 |
98 |
150 |
16 - 20 |
108 |
20 × 40 |
3000 |
| HM-VTF200 |
50 |
320 |
422 |
130 |
200 |
18 - 25 |
142 |
25 × 50 |
3000 |
| HM-VTF250 |
62.5 |
400 |
500 |
163 |
250 |
20 - 30 |
164 |
28 × 56 |
3500 |
| HM-VTF300 |
75 |
480 |
595 |
195 |
300 |
25 - 32 |
194 |
28 × 56 |
3500 |
| HM-VTF400 |
100 |
640 |
808 |
260 |
400 |
25 - 32 |
266 |
35 × 70 |
3500 |
| HM-VTF500 |
125 |
800 |
981 |
325 |
500 |
25 - 32 |
318 |
42 × 84 |
3500 |
| HM-VTF600 |
150 |
960 |
1160 |
390 |
600 |
28 - 40 |
373 |
48 × 96 |
3000 |
| HM-VTF800 |
200 |
1300 |
1550 |
520 |
800 |
41 - 50 |
499 |
54 × 108 |
3000 |
| HM-VTF1000 |
250 |
1550 |
1850 |
650 |
1000 |
50 - 62 |
580 |
54 × 108 |
3000 |
| *Note: Other sizes can be customized according to the requirements. |
Features
Low Maintenance
Requires only annual visual inspection and occasional cleaning, with no lubrication or adjustments needed.
Non Marking Surface
Special compound formulation prevents transfer of rubber marks to vessel hulls during contact.
Fire Resistant Options
IMO-certified fireproof versions available for LNG terminals and oil platforms (meeting FTP Code Part 2).
Eco Friendly Materials
Recyclable rubber compounds and manufacturing processes with low VOC emissions.
Applications
● Commercial Ports
● Oil Terminals
● Container Terminals
● Bulk Cargo Ports
● Cruise Ship Docks
Advantages
Global Certification Compliance
Products meet all major international standards including PIANC, OCIMF, and ISO 17357-1 requirements.
Technical Support Team
Dedicated engineering staff providing application consulting, installation guidance, and maintenance recommendations.
Competitive Production Lead Times
Efficient manufacturing workflow enables reliable delivery schedules even for large-volume orders.
Environmentally Responsible Manufacturing
Sustainable production practices with energy-efficient processes and recyclable material usage.
FAQ
1. Q: Do you provide installation supervision services?
A: Yes, our engineers can provide on-site installation guidance for complex projects.
2. Q: How are wear indicators incorporated into your fenders?
A: Optional colored layers at specific depths visually indicate when 50% and 80% of wear life has been reached.
3. Q: What's the difference between solid and hollow V-Type Fenders?
A: Hollow designs offer weight savings (30-40% lighter) while maintaining similar performance characteristics.
4. Q: Can V-Type Fenders be repaired if damaged?
A: Minor damage can often be repaired, but severely damaged sections should be replaced.
