NBR 800 V Type Rubber Fender Marine Safety Dock Rubber Fender Tear Resistance
Description
The v type rubber fender is also known as arch rubber fender is a kind of marine rubber fender, which can also be embedded in the steel mount and nut on the top of the fender. It connects the front panel, UHMW-PE face pad installed outside of the front panel, which lowers the friction factor between vessel and fender to avoid the damage of vessel and raises the utility of fender life.
The regular V Type Fender has a rubber contact face ideal for all general purpose applications. The higher friction of the rubber surface can be used to good effect to dampen the movements between vessel and wharf in sea swells and similar conditions.
Specifications
| Product Name | NBR 800 V Type Rubber Fender Marine Safety Dock Rubber Fender Tear Resistance |
| Brand Name | DockFender |
| Model Number | DF-V800H |
| Material | High Performance Natural Rubber |
| Color | Black and Customers' Requirements |
| Shape | V Type |
| Standard | HGT2866-2016, PIANC2002 |
| Hardness | 40-70 Shore A |
| Elongation | => 400 |
| Tear Strength | => 400 N/cm |
| Breaking Strength | >310 |
| Chemical Resistance | Fuel A: No deterioration |
| Oil 3: No deterioration | |
| Lubricating oil: No deterioration | |
| Cutting oil: No deterioration | |
| Dilute HCL: No deterioration |
| Model | A | D | E | F | H | K | M | R x Q | Lmax |
| V Type | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] |
| DF-V150 | 50 | 240 | 326 | 98 | 150 | 16 - 20 | 108 | 20 × 40 | 3000 |
| DF-V200 | 50 | 320 | 422 | 130 | 200 | 18 - 25 | 142 | 25 × 50 | 3000 |
| DF-V250 | 62.5 | 400 | 500 | 163 | 250 | 20 - 30 | 164 | 28 × 56 | 3500 |
| DF-V300 | 75 | 480 | 595 | 195 | 300 | 25 - 32 | 194 | 28 × 56 | 3500 |
| DF-V400 | 100 | 640 | 808 | 260 | 400 | 25 - 32 | 266 | 35 × 70 | 3500 |
| DF-V500 | 125 | 800 | 981 | 325 | 500 | 25 - 32 | 318 | 42 × 84 | 3500 |
| DF-V600 | 150 | 960 | 1160 | 390 | 600 | 28 - 40 | 373 | 48 × 96 | 3000 |
| DF-V800 | 200 | 1300 | 1550 | 520 | 800 | 41 - 50 | 499 | 54 × 108 | 3000 |
| DF-V1000 | 250 | 1550 | 1850 | 650 | 1000 | 50 - 62 | 580 | 54 × 108 | 3000 |
| *Note: Other sizes can be customized according to the requirements. | |||||||||
Features
1. Rugged single piece moulding for long service life.
2. Strong bolting arrangement is easy and quick to install.
3 Excellent shear resistance means shear chains rarely needed.
4. Large range of sizes, lengths and Energy Indices.
Applications
● General cargo terminals
● Bulk terminals
● Berth for tug boats
● Multi-purpose terminals
● RoRo ramps
● Passenger vessel terminals
● Barge
Advantages
◆ 32 years of professional manufacturing experience in rubber fender.
◆ Raw material testing machine, complete production line and finished product inspection equipment.
◆ ISO9001, 14001, certification of other classification societies.
◆ Excellent impact resistance: UHMWPE material not only has good wear resistance, but also has high impact resistance. Its impact strength is greater than 140 kg/ cm.
◆ The raw materials are safe and the effect is remarkable.
