Chemical STS Hose Chemical Resistance Oil Lightweight Design
Description
The High-Pressure STS Marine Transfer Hose represents the pinnacle of marine cargo transfer technology, specifically engineered to handle extreme pressure conditions and challenging marine environments. Featuring a specialized inner lining and robust external reinforcement, this hose can withstand significant operational pressures while maintaining optimal flexibility and performance. Its advanced construction ensures maximum safety and efficiency during ship-to-ship transfer operations.
This innovative hose offers numerous advantages, including exceptional pressure resistance up to 25 bar, superior chemical compatibility, and remarkable abrasion resistance. It is particularly suitable for complex marine transfer operations involving crude oil, refined products, and chemical substances. The hose's unique design minimizes product loss, reduces environmental risks, and provides unprecedented reliability in the most demanding maritime transfer scenarios.
Specifications
| Material |
PTFE, Galvanized Steel Wire, PVC Coated Polyester Cloth |
| Product Name |
Chemical STS Hose Chemical Resistance Oil Lightweight Design |
| Size |
HM-SH14 |
| Inner Wire |
Stainless Steel 316 |
| Lining |
Polyamide |
| Carcass |
Polyamide fabrics, Polyester films |
| Outer Wire |
Stainless Steel 316 |
| Working Pressure |
10 bar to 21 bar |
| Maximum Length |
40 meters |
| Sample |
Available |
| Delivery time |
Normally 3-5 days |
| Model |
Dimensions |
Working Pressure |
Safety Factor |
Bending Radius |
Weight |
Length |
| Composite |
[mm] |
[inch] |
[bar] |
[psi] |
[kg] |
[m] |
| HM-SH20 |
20 |
3/4" |
16 |
230 |
6:1 |
80 |
0.8 |
40 |
| HM-SH25 |
25 |
1" |
16 |
230 |
6:1 |
100 |
1 |
40 |
| HM-SH32 |
32 |
11/4" |
16 |
230 |
6:1 |
125 |
1.3 |
40 |
| HM-SH40 |
40 |
11/2" |
16 |
230 |
6:1 |
140 |
1.5 |
40 |
| HM-SH50 |
50 |
2" |
16 |
230 |
6:1 |
180 |
2.5 |
40 |
| HM-SH65 |
65 |
21/2" |
16 |
230 |
6:1 |
200 |
3.3 |
40 |
| HM-SH80 |
80 |
3" |
16 |
230 |
6:1 |
260 |
4 |
40 |
| HM-SH100 |
100 |
4" |
16 |
230 |
6:1 |
380 |
6.8 |
40 |
| HM-SH125 |
125 |
5" |
16 |
230 |
6:1 |
440 |
9.2 |
40 |
| HM-SH150 |
150 |
6" |
16 |
230 |
6:1 |
500 |
13.2 |
40 |
| HM-SH200 |
200 |
8" |
16 |
230 |
6:1 |
750 |
18 |
40 |
| HM-SH250 |
250 |
10" |
16 |
230 |
6:1 |
900 |
26 |
25 |
| *Note: Various sizes can be customized according to the requirements. |
Features
Safety Compliance
STS hoses are manufactured to meet rigorous safety standards, minimizing the risk of leaks or failures, thereby protecting both personnel and the environment.
Temperature Resistance
Capable of withstanding extreme temperatures, STS hoses perform reliably in both high-heat and cryogenic applications, expanding their usability across different sectors.
Low Maintenance
Designed for minimal upkeep, STS hoses reduce operational costs by decreasing the need for frequent replacements or repairs, ensuring uninterrupted workflow.
Smooth Inner Surface
The hoses feature a smooth inner lining that promotes efficient fluid flow and reduces turbulence, ultimately enhancing performance and longevity.
Applications
● Oil Transfer Operations
● Loading and Unloading of Fuel
● Ship Waste Disposal
● Chemical Transfer
Advantages
Reliable Performance
Our STS hoses are designed to withstand extreme conditions, ensuring reliable performance in the most demanding applications, which our clients have come to trust over the years.
Experienced Workforce
Our team consists of highly skilled professionals with extensive knowledge in hose manufacturing, allowing us to maintain a strong reputation for craftsmanship and attention to detail.
Comprehensive Product Range
We offer a wide variety of STS hoses suitable for diverse applications, from fuel transfer to chemical handling, ensuring we can support all your needs.
Sustainability Focus
We are dedicated to sustainable manufacturing practices, minimizing waste and using environmentally friendly materials to promote a healthier planet.
