Name: PIANC2002 Black Roller Fenders 3 MPA Intensity For Boat Dock Buffer
Brand: Hongruntong Marine Co., Ltd.
SKU: DF-D1980
Price: 3,010.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: PIANC2002 Specifications Roller Fenders D1980 Colorful Customized For Boat Dock Buffer

Material: High Density NR/NBR/SBR

Type: Fixed Wheel Fender

Hardness: ≤82 Shore A

Logo: Customized Logo Accept

Usage: For Ship Docking Or Berthing

Install: Exposed Corners

Packing: Plastic Bag+Pallet

Highlight:

PIANC2002 Roller Fenders

Roller Fenders 3 MPA

Basic Infomation

Place of Origin: CHINA

Brand Name: DockFender

Certification: ABS, DNV, CCS, PIANC

Model Number: DF-D1980

Payment & Shipping Terms

Packaging Details: Wooden pallet or as required

Delivery Time: 7-9 Work Days

Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability: 2210 Pcs Per Month

Gallery

PIANC2002 Black Roller Fenders 3 MPA Intensity For Boat Dock Buffer

Product Description

PIANC2002 Specifications Roller Fenders D1980 Colorful Customized For Boat Dock Buffer

Description

The Roller Fenders (Wheel Fenders) are more complex than the simply constructed Roller Fender. They are designed with maintenance-free bearings, typically from stainless steel, and composite material. Due to the Wheel Fender's design, using additional back rollers and a sliding shaft, they provide a higher energy absorption. Wheel Fenders come in certain standard sizes but typically each project requires a unique design.

Specifications

Item No.	DF-D1980
Product Name	PIANC2002 Specifications Roller Fenders D1980 Colorful Customized For Boat Dock Buffer
Material	High Density NR/NBR/SBR
Temperature	From -30°C To 70°C
Specific Gravity	1.45 g/cm3
Intensity	3 MPA
Hardness	65 ± 5 shore A
Elongation	≥300%
Size	D1080-2900mm
Package	By Pallets, By carton, By iron cage
Color	Black, As Required
Certificate	CE, ROHS, REACH, SGS, MSDS, ISO9001
Experience	32 years
Market	North America, Asia, Europe, South America, Australia, Africa.
Payment	BANK TRANSFER, 30% T/T, Balance Before Shipment, L/C.

1. Wheel Type

PIANC2002 Black Roller Fenders 3 MPA Intensity For Boat Dock Buffer 0

Model No.	A	B	C	D	E	F	H
Wheel	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]
DF-D1080	1700	1000	1450	1080	900	350	460
DF-D1300	2000	1200	1750	1300	1000	350	510
DF-D1750	2650	1500	2200	1750	1150	550	690
DF-D1980	2750	1750	2550	1980	1250	500	760
DF-D2550	3350	2200	3200	2550	1600	850	970
DF-D2900	4200	2500	3750	2900	1700	1000	900

2. Roller Type

PIANC2002 Black Roller Fenders 3 MPA Intensity For Boat Dock Buffer 1

Model No.	A	B	C	D	E	G	H	J	K	L
Roller	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]
DF-D1080	1250	1150	610	1080	1150	220	460	800	340	60
DF-D1450	1530	1400	740	1320	1450	260	510	950	400	75
DF-D1500	1600	1450	765	1370	1500	270	610	1000	425	75
DF-D1900	2050	1850	975	1750	1900	350	690	1250	500	125
DF-D2100	2300	2100	1110	1980	2100	400	765	1400	550	150
DF-D2700	3000	2700	1425	2550	2700	500	895	1800	700	200

3. Cushion Type

PIANC2002 Black Roller Fenders 3 MPA Intensity For Boat Dock Buffer 2

Model No.	Capacity	A	B	C	D	T	W	a1	a2	a3	b1	b2
Cushion	Tons	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]
DF-CR10	10T	450	450	542	370	130	125	90	310	–	35	380
DF-CR15	15T	450	450	542	370	130	190	90	175	135	35	380
DF-CR20	20T	450	520	546	370	130	250	80	160	120	50	420
DF-CR25	25T	450	550	546	370	130	315	90	175	135	35	480
DF-CR30	30T	480	630	570	380	130	315	90	180	120	55	520
DF-CR40	40T	770	725	690	450	200	350	120	300	300	70	585

Features

1. Good energy absorption.

2. Gentle contact face.

3. Low maintenance frame design.

4. Used singly or in multiple stacks.

5. Low maintenance frame design.

6. Composite and stainless steel bearings.

Applications

● Lock approaches

● Dry- Dock entrances and walls

● Narrow entries, exits & corners

Advantages

1. Quality: DockFender roller fenders always maintain high quality. We insist on using 100% natural rubber, coupled with a special angle design, so that our roller rubber fenders can be more durable and perform better.

2. Service: DockFender adheres to the principle of customer first. Our professional customer service team can not only provide you with the most professional product recommendations, but also help you customize project solutions.

3. After-sales Service: DockFender 's solid arch fenders can be guaranteed for 24 months. As long as you use it normally, we can guarantee replacement for any product quality problems during the warranty period.

4. Customize: All products of DockFender can be specially customized according to customer requirements, let us know your needs!

PIANC2002 Black Roller Fenders 3 MPA Intensity For Boat Dock Buffer 3

PIANC2002 Black Roller Fenders 3 MPA Intensity For Boat Dock Buffer 4

PIANC2002 Black Roller Fenders 3 MPA Intensity For Boat Dock Buffer 5
