NR D Type Rubber Fenders in Sizes Up to 300mm Compact Yet Strong
Description
Hongruntong Marine’s Standard D Type Rubber Fender is engineered to deliver reliable protection for docks, quaysides, and small to medium vessels. Its simple, robust design provides excellent resistance to abrasion and impact, making it an ideal solution for general marine fendering applications.
Manufactured using high-quality natural or synthetic rubber, these fenders offer long service life with minimal maintenance. Easy to install and available in multiple sizes and lengths, our D Fenders ensure cost-effective, long-term protection for marine structures.
Specifications
Product Name | D Type Fenders |
Brand Name | Hongruntong Marine |
Material | High Performance Natural Rubber |
Color | Black and Customers' Requirements |
Type | Fixed D Rubber Fenders |
Standard | HGT2866-2016, PIANC2002 |
Energy Absorption | 147kN to 920kN |
Reaction Force | 5.1KN-M to 64KN-M |
Application | Port, Dock, Quay, etc |
A | B | C | D | E | F | H | K |
[mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] |
70 | 30 | 15 | 30 | 45 | 80 | 90 - 130 | 200 - 300 |
100 | 45 | 15 | 30 | 50 | 100 | 90 - 130 | 200 - 300 |
125 | 60 | 20 | 40 | 60 | 125 | 110 - 150 | 250 - 300 |
150 | 75 | 20 | 40 | 75 | 150 | 110 - 150 | 250 - 300 |
150 | 80 | 25 | 50 | 100 | 200 | 130 - 180 | 300 - 400 |
200 | 100 | 25 | 50 | 100 | 200 | 130 - 180 | 300 - 400 |
200 | 100 | 30 | 60 | 125 | 250 | 140 - 200 | 350 - 450 |
250 | 125 | 30 | 60 | 125 | 250 | 140 - 200 | 350 - 450 |
300 | 150 | 30 | 60 | 150 | 300 | 140 - 200 | 350 - 450 |
350 | 175 | 35 | 75 | 175 | 350 | 140 - 200 | 350 - 450 |
380 | 190 | 35 | 75 | 190 | 380 | 140 - 200 | 350 - 450 |
300 | 150 | 35 | 75 | 175 | 400 | 140 - 200 | 350 - 450 |
400 | 200 | 35 | 75 | 200 | 400 | 140 - 200 | 350 - 450 |
500 | 250 | 45 | 90 | 250 | 500 | 160 - 230 | 400 - 500 |
*Note: Other sizes can be customized according to the requirements. |
A | B | C | D | E | F | G | H | K |
[mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] |
100 | 25 | 10 | 30 | 15 | 100 | 50 | 90 - 130 | 200 - 300 |
150 | 30 | 12 | 65 | 20 | 150 | 75 | 110 - 150 | 250 - 350 |
200 | 45 | 15 | 75 | 25 | 200 | 100 | 130 - 180 | 300 - 400 |
250 | 50 | 20 | 100 | 30 | 250 | 125 | 140 - 200 | 350 - 450 |
300 | 60 | 25 | 125 | 30 | 300 | 150 | 140 - 200 | 350 - 450 |
350 | 70 | 25 | 150 | 35 | 350 | 175 | 140 - 200 | 350 - 450 |
400 | 80 | 30 | 175 | 35 | 400 | 200 | 140 - 200 | 350 - 450 |
400 | 80 | 30 | 200 | 35 | 400 | 200 | 140 - 200 | 350 - 450 |
500 | 100 | 30 | 250 | 35 | 500 | 250 | 140 - 200 | 350 - 450 |
Features
Smooth Surface for Safe Contact
Designed to minimize damage or marks on vessel hulls during contact.
Extruded for Consistent Quality
Produced using extrusion methods that ensure even density and dimensional accuracy.
Environmentally Friendly Materials
Manufactured using recyclable rubber with reduced environmental impact.
Can Be Reinforced with Steel or Fabric Layers
Optional reinforcement increases strength and load capacity for heavy-duty use.
Applications
● Tanker docking stations
Advantages
Over 30 Years of Manufacturing Experience
A proven track record in rubber fender production since the early 1990s.
Specialized in D Type Rubber Fenders
Full focus on design, development, and production of D-type fender solutions.
In House Production Quality Control
All products are manufactured under strict in-house QA systems for consistent quality.
ISO Certified Manufacturing Facility
Fully compliant with ISO 9001 and international marine product standards.
FAQ
1. Q: Do you accept third-party inspections like SGS or BV?
A: Absolutely, we fully support third-party inspections requested by clients.
2. Q: What’s your warranty policy?
A: We offer a 12–24 month warranty depending on the product type and application.
3. Q: Can you provide certificates of origin or quality reports?
A: Yes, CO, mill certificates, and test reports can be issued upon request.
4. Q: Why should we choose Hongruntong Marine as our supplier?
A: We have over 30 years of experience, offer competitive pricing, fast delivery, full customization, and strict quality control to ensure satisfaction.
