Cost Effective D Profile Fenders with Strong Performance and Long Service Life
Description
Our Solid D Type Fenders are specifically designed for use on tugboats, workboats, and service vessels where high durability is essential. With their thick rubber body and excellent energy absorption capabilities, they offer reliable defense against frequent contact and heavy berthing operations.
Hongruntong Marine uses premium-grade rubber compounds to ensure maximum resistance to seawater, UV, and aging. Custom lengths, pre-drilled mounting holes, and steel insert options are available to meet diverse installation requirements.
Specifications
| Product Name |
D Type Fenders |
| Brand Name |
Hongruntong Marine |
| Material |
High Performance Natural Rubber |
| Color |
Black and Customers' Requirements |
| Type |
Fixed D Rubber Fenders |
| Standard |
HGT2866-2016, PIANC2002 |
| Energy Absorption |
147kN to 920kN |
| Reaction Force |
5.1KN-M to 64KN-M |
| Application |
Port, Dock, Quay, etc |
| A |
B |
C |
D |
E |
F |
H |
K |
| [mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
| 70 |
30 |
15 |
30 |
45 |
80 |
90 - 130 |
200 - 300 |
| 100 |
45 |
15 |
30 |
50 |
100 |
90 - 130 |
200 - 300 |
| 125 |
60 |
20 |
40 |
60 |
125 |
110 - 150 |
250 - 300 |
| 150 |
75 |
20 |
40 |
75 |
150 |
110 - 150 |
250 - 300 |
| 150 |
80 |
25 |
50 |
100 |
200 |
130 - 180 |
300 - 400 |
| 200 |
100 |
25 |
50 |
100 |
200 |
130 - 180 |
300 - 400 |
| 200 |
100 |
30 |
60 |
125 |
250 |
140 - 200 |
350 - 450 |
| 250 |
125 |
30 |
60 |
125 |
250 |
140 - 200 |
350 - 450 |
| 300 |
150 |
30 |
60 |
150 |
300 |
140 - 200 |
350 - 450 |
| 350 |
175 |
35 |
75 |
175 |
350 |
140 - 200 |
350 - 450 |
| 380 |
190 |
35 |
75 |
190 |
380 |
140 - 200 |
350 - 450 |
| 300 |
150 |
35 |
75 |
175 |
400 |
140 - 200 |
350 - 450 |
| 400 |
200 |
35 |
75 |
200 |
400 |
140 - 200 |
350 - 450 |
| 500 |
250 |
45 |
90 |
250 |
500 |
160 - 230 |
400 - 500 |
| *Note: Other sizes can be customized according to the requirements. |
| A |
B |
C |
D |
E |
F |
G |
H |
K |
| [mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
| 100 |
25 |
10 |
30 |
15 |
100 |
50 |
90 - 130 |
200 - 300 |
| 150 |
30 |
12 |
65 |
20 |
150 |
75 |
110 - 150 |
250 - 350 |
| 200 |
45 |
15 |
75 |
25 |
200 |
100 |
130 - 180 |
300 - 400 |
| 250 |
50 |
20 |
100 |
30 |
250 |
125 |
140 - 200 |
350 - 450 |
| 300 |
60 |
25 |
125 |
30 |
300 |
150 |
140 - 200 |
350 - 450 |
| 350 |
70 |
25 |
150 |
35 |
350 |
175 |
140 - 200 |
350 - 450 |
| 400 |
80 |
30 |
175 |
35 |
400 |
200 |
140 - 200 |
350 - 450 |
| 400 |
80 |
30 |
200 |
35 |
400 |
200 |
140 - 200 |
350 - 450 |
| 500 |
100 |
30 |
250 |
35 |
500 |
250 |
140 - 200 |
350 - 450 |
Features
Cost Effective Protection
A highly economical solution for long-term marine and dockside defense.
Low Maintenance Requirement
Durable material and construction reduce the need for frequent inspection and replacement.
Shock and Vibration Absorption
Helps reduce vessel vibrations during berthing, protecting cargo and equipment.
Ideal for Small and Medium Vessels
Commonly used on tugboats, fishing boats, workboats, pontoons, and jetties.
Applications
● Coastal facilities
● Bulk carrier loading/unloading areas
● Naval bases
● Harbor berths
● Cargo handling facilities
Advantages
Advanced Rubber Formulation Technology
Use of proprietary rubber compounds for superior performance and longevity.
Customized Solutions Available
We design and produce D fenders in custom lengths, hardness, and mounting styles.
Precision Extrusion Equipment
High-precision extrusion lines ensure uniformity in shape, density, and quality.
Comprehensive Size Range
Standard D Fenders from 100mm to 600mm height, with customizable dimensions.
FAQ
1. Q: Do you conduct product testing?
A: Yes, we perform hardness, tensile strength, elongation, compression, and aging resistance tests in-house.
2. Q: What countries do you export to?
A: We export to over 40 countries, including the USA, UAE, Singapore, Australia, and European markets.
3. Q: Can we use your fenders in freshwater and saltwater?
A: Yes, our rubber formulation is resistant to both fresh and seawater environments.
4. Q: Are the fenders environmentally friendly?
A: Yes, our fenders are made with recyclable materials and non-toxic compounds.
