Non Toxic Materials Submarine Fenders With Resistant To Oil And Grease

1
MOQ
USD65 to 697 Per Piece
Price
Non Toxic Materials Submarine Fenders With Resistant To Oil And Grease
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Submarine Fenders
Advantage: Customized, Original Factory
Warranty: 36 Months
Length: 1 ~ 12m
Application: Submarine Dock Fender
Pressure: 50 KPA ~ 80 KPA
Material: Top Level Natural Rubber
Diameter: 0.5 ~ 4.5m
Standard: ISO17357:2014
Highlight:

Non Toxic Submarine Fenders

,

Oil Resistant Submarine Fenders

,

Grease Resistant Submarine Fenders

Basic Infomation
Place of Origin: China
Brand Name: Hongruntong Marine
Certification: ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
Model Number: HM-SF52
Payment & Shipping Terms
Packaging Details: Wooden Pallets, Wooden Cases or as Required
Delivery Time: 5-6 Work Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2510 Units Per Months
Product Description

Non Toxic Materials Submarine Fenders With Resistant To Oil And Grease



Description



Submarine fenders are advanced marine buffers that protect underwater installations from mechanical shocks and abrasive forces. Their specialized construction combines elasticity with high load-bearing capacity, making them ideal for challenging subsea conditions. These fenders are resistant to biofouling, UV radiation, and chemical exposure, ensuring reliable performance over extended periods. Used in offshore wind farms, oil rigs, and underwater cables, they help mitigate risks associated with vessel impacts and tidal movements. Their modular design allows for easy integration into existing marine infrastructure, providing a sustainable and efficient solution for subsea protection.



Non Toxic Materials Submarine Fenders With Resistant To Oil And Grease 0Non Toxic Materials Submarine Fenders With Resistant To Oil And Grease 1Non Toxic Materials Submarine Fenders With Resistant To Oil And Grease 2





Specifications



Material SBR, NR
Size Available 3.3*10.6M
Tensile Strength => 18 MPA
Density 90+/-5
Colour Black
Application Submarine, ferry, oil rigs and so on
Hardness 40-70 Shore A
Elongation => 400
Tear Strength => 400 N/cm
Breaking Strength >310

Chemical Resistance









Fuel A: No deterioration
Oil 3: No deterioration
Lubricating oil: No deterioration
Cutting oil: No deterioration
Dilute HCL: No deterioration



Diameter x
Length
Initial
Internal
Pressure
Ship
Radius
Water
Ratio
Guaranteed
Energy
Absorption
Reaction
Force
at GEA
Hull
Pressure
at GEA
Deflection
at GEA
(mm x mm) (kPa) (mm) (%) (kJ) (kN) (kPa) (%)
1500 x 6100 50 3000 60% 131 562 140 51%
80 186 754 188
1700 x 7200 50 4000 65% 167 682 137 47%
80 239 918 184
2000 x 6000 50 4000 70% 135 544 131 41%
80 194 736 177
2500 x 5500 50 4500 65% 225 769 135 41%
80 322 1035 182
2500 x 7700 50 4500 70% 326 1016 136 41%
80 470 1368 183
3300 x 6500 50 4500 75% 307 887 127 35%
80 442 1203 173
3300 x 10600 50 5000 65% 1003 2137 142 47%
80 1429 2863 190
4500 x 9000 50 5000 60% 1439 2401 138 46%
80 2059 3228 185
4500 x 12000 50 6000 65% 1977 3198 141 46%
80 2819 4277 189





Characteristics



Advanced Shock Dampening
Minimizes vibration and impact forces, reducing stress on pipelines, risers, and mooring systems.

Customizable Designs
Tailored shapes, sizes, and stiffness to meet specific project requirements and environmental conditions.

Low Maintenance Long Lifespan
Requires minimal upkeep while delivering years of reliable service, reducing operational costs.

UV Chemical Resistance
Withstands harsh sunlight, oil, grease, and other corrosive substances for extended durability.





Applications



● Special Forces Deployment Areas


Military Ports

Research Submarine Facilities





Advantages



Precision Manufacturing
Advanced production techniques and strict quality control deliver consistent, high-tolerance products.

Proven Track Record with Global Clients
Trusted by military and commercial clients in over 40 countries.

Strong RD Capabilities
In-house research and development allow us to innovate and stay ahead of industry demands.

Compliance with International Standards
Our submarine fenders comply with ISO, PIANC, and military standards for marine fender systems.


Non Toxic Materials Submarine Fenders With Resistant To Oil And Grease 3Non Toxic Materials Submarine Fenders With Resistant To Oil And Grease 4





FAQ



1. Do you offer certifications or testing reports?
Yes, we provide full test reports, including compression, energy absorption, and material compliance documentation.

2. What maintenance is required for submarine fenders?
Periodic inspection for wear, pressure checks (for pneumatic types), and surface cleaning are recommended.

3. Do your fenders work in cold or icy environments?
Yes, our fenders are operational in temperatures as low as -40°C, making them suitable for polar regions.

4 What types of submarine fenders do you manufacture?
We offer cylindrical, rectangular, and pneumatic fenders specifically designed for submarine use.
