International Certification Jumbo Fender With Improved Shock Absorption And Low Maintenance
Description
The Yokohama Rubber Fender is essential for safe and efficient berthing in ports, harbors, and offshore facilities. Its pneumatic cushioning effect minimizes the impact force between vessels and docks, reducing structural damage. It is commonly used in oil terminals, container ports, naval bases, and ship-to-ship (STS) operations. Due to its ability to function in varied tidal conditions, it is highly preferred for floating dock applications. The fender’s reliability, durability, and cost-effectiveness make it a standard solution for international maritime operations, ensuring the protection of both vessels and port infrastructure.
Specifications
| Place of Origin |
China |
| Brand Name |
Yokohama Rubber Fender |
| Model Number |
HM-YRF7 |
| Material |
Natural Rubber |
| Color |
Black |
| Application |
In ports with extreme tidal variations
Ship-to-ship lightering operations
Oil Gas (typically FSRU)
Temporary berthing
|
| Feature |
Heat Resistance |
| Sample |
Usually free |
| Production Method |
Moulding |
| Temperature |
-40℃~300℃ |
| Packing |
Pallets |
| Lead time |
7-14 days |
Diameter x Length
[mm] |
50kPa
Performance Data |
80kPa
Performance Data |
Hull Pressure
at GEA
/ kN / m2 |
Reaction Force
/ kN |
Energy Absorption
/ kNm |
Hull Pressure
at GEA
/ kN / m2 |
Reaction Force
/ kN |
Energy Absorption
/ kNm |
| 1000 x 1500 |
122 |
182 |
32 |
160 |
239 |
45 |
| 1000 x 2000 |
132 |
257 |
45 |
174 |
338 |
63 |
| 1200 x 2000 |
126 |
297 |
63 |
166 |
390 |
88 |
| 1350 x 2500 |
130 |
427 |
102 |
170 |
561 |
142 |
| 1500 x 3000 |
153 |
579 |
153 |
174 |
761 |
214 |
| 1700 x 3000 |
128 |
639 |
191 |
168 |
840 |
267 |
| 2000 x 3500 |
128 |
875 |
308 |
168 |
1150 |
430 |
| 2500 x 4000 |
137 |
1381 |
663 |
180 |
1815 |
925 |
| 2500 x 5500 |
148 |
2019 |
943 |
195 |
2653 |
1317 |
| 3300 x 4500 |
130 |
1884 |
1175 |
171 |
2476 |
1640 |
| 3300 x 6500 |
146 |
3015 |
1814 |
191 |
3961 |
2532 |
| 3300 x 10600 |
158 |
5257 |
3067 |
208 |
6907 |
4281 |
| 4500 x 9000 |
146 |
5747 |
4752 |
192 |
7551 |
6633 |
| * Other size can be produced follow client's requirements. |
Features
Improved Shock Absorption
Their design enables effective shock absorption, significantly reducing the impact force experienced by moored vessels.
Robust Performance in All Conditions
Yokohama fenders maintain consistent performance in different sea environments, be it calm or rough waters.
International Certification
Many Yokohama products are certified by international marine organizations, ensuring that they meet high safety and quality standards.
Expertise in Marine Applications
With extensive expertise, Yokohama's engineers continually improve their designs to address evolving marine challenges effectively.
Applications
● River and Canal Mooring
● Yacht Marinas
● Naval Bases
Advantages
Corrosion Weather Resistant
Withstands harsh marine environments, including saltwater and extreme temperatures.
Lightweight Portable
Easy to transport, install, and relocate as needed.
Self floating Capability
Floats on water, making it suitable for tidal changes and deepwater applications.
Minimal Maintenance Required
Designed for long-term use with minimal upkeep costs.
FAQ
1. How do I install Yokohama Fenders?
Installation guidelines are provided with the products, and we recommend following these instructions closely or consulting with a professional for the best results.
2. Can Yokohama Fenders be used in harsh weather conditions?
Yes, Yokohama fenders are designed to perform effectively in both calm and rough weather conditions, making them suitable for a wide range of marine environments.
3. Do Yokohama Fenders come with a warranty?
Yes, Yokohama typically offers warranties on its fender products, but the specifics may vary by model and region. It's best to check the warranty details during purchase.
4. How do I store Yokohama Fenders when not in use?
Fenders should be stored in a clean, dry, and shaded area, away from direct sunlight and extreme temperatures, to prolong their lifespan.
