Dock Rubber Fender Eco Friendly Materials Bumpers for Bulk Handling Ports
Description
Dock rubber fenders are specifically designed to provide high energy absorption capabilities, ensuring the safe mooring of vessels in various operating conditions. With advanced engineering and optimized material composition, these fenders effectively dissipate the impact energy generated during docking, reducing the likelihood of damage to both the vessel and the dock infrastructure. Their unique shape and resilience allow them to compress and expand under load, which accommodates the dynamic forces exerted by different boat sizes. This high energy absorption not only enhances the safety of mooring operations but also prolongs the life of the fenders themselves. As a crucial safety feature in busy maritime environments, dock rubber fenders with excellent energy-absorbing properties are essential for protecting investments in vessels and docking facilities, ensuring smooth and efficient operations at all times.
Specifications
| Place of Origin |
China |
| Brand Name |
DockFender |
| Product Name |
Dock Rubber Fender Eco Friendly Materials Bumpers for Bulk Handling Ports |
| Type |
D Shape Type |
| Processing Service |
Compression Moulded |
| Model Number |
HMDF-78 |
| Color |
Black (More colors optional) |
| Material |
Smooth NR |
| Performance |
Excellent chemical and physical property |
| Logo |
Customer's Request |
| Application |
Port, Dock, Boat |
| Type |
Specifications |
| H |
B |
L |
Holes |
Q |
C |
h |
D |
d |
| D150x150x1000 |
150 |
150 |
1000 |
3 |
350 |
150 |
25 |
40 |
24 |
| D200x200x1000 |
200 |
200 |
1000 |
3 |
353 |
150 |
35 |
55 |
30 |
| D200x200x3000 |
200 |
200 |
3000 |
8 |
400 |
100 |
35 |
55 |
30 |
| D250x250x1000 |
250 |
250 |
1000 |
3 |
350 |
150 |
35 |
60 |
30 |
| D250x250x3000 |
250 |
250 |
3000 |
8 |
400 |
100 |
35 |
60 |
30 |
| D300x300x1000 |
300 |
300 |
1000 |
3 |
350 |
150 |
40 |
65 |
32 |
| D300x300x3000 |
300 |
300 |
3000 |
8 |
400 |
100 |
40 |
65 |
32 |
| D300x360x1000 |
300 |
360 |
1000 |
3 |
350 |
150 |
40 |
65 |
32 |
| D300x360x3000 |
300 |
360 |
3000 |
8 |
400 |
100 |
40 |
65 |
40 |
| D400x400x1000 |
400 |
400 |
1000 |
3 |
400 |
150 |
55 |
80 |
32 |
| D400x400x3000 |
400 |
400 |
3000 |
8 |
400 |
100 |
55 |
80 |
40 |
| D500x500x1000 |
500 |
500 |
1000 |
3 |
350 |
150 |
90 |
97 |
45 |
| D500x500x3000 |
500 |
500 |
3000 |
8 |
400 |
100 |
90 |
97 |
45 |
| TECHNICAL DATA |
| PROPERTIES |
TEST STANDARD |
VALUES |
| Compound |
- |
NR / SBR |
| Density (Specific Gravity) |
DIN 53505 |
1200 kg/m3 |
| Tensile Strength |
DIN 53504 |
≥16 MPa |
| Elongation at Break |
DIN 53504 |
≥350% |
| Tear Resistance (23°C) |
DIN 53507 |
≥80 N/cm |
| Abrasion Resistance |
DIN 53516 |
≤100mm3 |
| Compression Set (24hrs @ 70°C) |
DIN 53517 |
≤40% |
| Ozone Resistance (ppm 20% 72hrs @ 40°C) |
ISO 143/1 |
No cracking visible by eye |
| Change In Hardness |
DIN 53504 |
≤5° |
| Change In Tensile Strength |
DIN 53504 |
≥80% |
| Change In Elongation at Break |
DIN 53504 |
≥80% |
| Minimum Temperature |
- |
-30°C |
| Maximum Temperature |
- |
+70°C |
Features
Low Maintenance Requirements
These fenders require minimal upkeep, as they do not need regular maintenance, making them a cost-effective option for long-term use.
Customizable Options
Many manufacturers offer customized fender solutions, allowing for tailored shapes and sizes to meet specific docking requirements or spatial constraints.
Environmental Resistance
Dock rubber fenders are engineered to withstand various environmental challenges, including UV radiation, seawater, and temperature fluctuations, preserving their integrity over time.
Enhanced Safety
The soft rubber surface of these fenders provides a cushioning effect, helping to protect personnel and vessels from injury and damage during docking and undocking operations.
Applications
● Oil and Gas Terminals
● Container Shipping Docks
● Naval Bases
● Passenger Ferry Terminals
Rigorous Quality Control
We implement strict quality assurance measures throughout the manufacturing process, guaranteeing that each dock rubber fender meets international standards and client expectations.
Competitive Pricing
Leveraging our extensive manufacturing experience enables us to offer high-quality products at competitive prices, providing excellent value for our customers.
Responsive Customer Service
Our dedicated team is committed to providing timely support and guidance, ensuring a smooth procurement process and reliable after-sales service.
Strong Reputation
Over the years, we have built a solid reputation for excellence in the marine industry, with numerous satisfied clients and successful projects showcasing our commitment to quality and reliability.
FAQ
Q: Are you manufacture or trade company ?
A:we are real factory with competive price, please contact to us freely .
Q: what is your MOQ ?If we only need one. Can you produce it?
A:Our MOQ can be 1 pcs. if what you need is our standard size product, we can produce it too when we produce other products of the same size. we produce other products of the same size. if you need non-standard products, we can customize them according to your requirements. contact to us for the negotiation.
Q: How about the lifespan of your Marine rubber fender?
A:Designed lifespan of our Marine rubber fender is about more than 10 years.
Q: What's your warranty period ?
A:Our warranty period is 2 years. we will responsible for the repairment or replace the new ones for you if it proved to be our
quality problem.
Q: what is your transportation way?
A: by ship or air are all ok, it can be ship out as customers request.
Q: What kind of certificate can you provide?
A: ISO9001, ISO14001, OHSAS10081, BV, CCS, LR, DNV, SGS, etc. certificate is available. ( if you need special requirment, please contactto us freely ).
