Good Price Country Of Origin Baby Size Yokohama Style Type Fender Catalogue/Certificate
Description
Yokohama Rubber Fenders are high-performance rubber fenders designed to provide optimal protection to ships during berthing. They are designed to absorb the impact energy of a ship and distribute it evenly, reducing the risk of damage to both the ship and the port infrastructure.
The fenders are made of high-quality rubber material, which is resistant to harsh weather conditions, chemicals, and UV exposure. They are also designed to withstand high impact forces, making them suitable for use in heavy-duty marine applications.
Yokohama Rubber Fenders come in various shapes and sizes to suit different types of vessels and berthing conditions. They can be customized to meet the specific requirements of a port or a ship, and they are also easy to install and maintain.
Overall, Yokohama Rubber Fenders offer a reliable and cost-effective solution to protect ships and ports from damage, ensuring safe and efficient operations in the maritime industry.
Specifications
Product Name | Yokohama Rubber Fender |
Material Type | NR,NBR,EPDM,SILICONE,FKM,SBR,etc. |
Hardness Range | 60 Shore A |
Color | Black, any color is OK |
Size | As per drawing dimensions |
Tolerance Standard | ISO2768-M or ISO3302-1:2014 CLASS M2 |
Material Characteristic | High resilience, flexibility, and excellent shock absorption |
Application | For all industries |
Certificates | DNV, ABS, LR, SGS, BV, CCS |
OEM / ODM | Available |
Packing Details | PE plastic bags then to the pallet or case / as per your request |
Diameter x Length [mm] |
50kPa Performance Data |
80kPa Performance Data |
||||
Hull Pressure at GEA / kN / m2 |
Reaction Force / kN |
Energy Absorption / kNm |
Hull Pressure at GEA / kN / m2 |
Reaction Force / kN |
Energy Absorption / kNm |
|
1000 x 1500 | 122 | 182 | 32 | 160 | 239 | 45 |
1000 x 2000 | 132 | 257 | 45 | 174 | 338 | 63 |
1200 x 2000 | 126 | 297 | 63 | 166 | 390 | 88 |
1350 x 2500 | 130 | 427 | 102 | 170 | 561 | 142 |
1500 x 3000 | 153 | 579 | 153 | 174 | 761 | 214 |
1700 x 3000 | 128 | 639 | 191 | 168 | 840 | 267 |
2000 x 3500 | 128 | 875 | 308 | 168 | 1150 | 430 |
2500 x 4000 | 137 | 1381 | 663 | 180 | 1815 | 925 |
2500 x 5500 | 148 | 2019 | 943 | 195 | 2653 | 1317 |
3300 x 4500 | 130 | 1884 | 1175 | 171 | 2476 | 1640 |
3300 x 6500 | 146 | 3015 | 1814 | 191 | 3961 | 2532 |
3300 x 10600 | 158 | 5257 | 3067 | 208 | 6907 | 4281 |
4500 x 9000 | 146 | 5747 | 4752 | 192 | 7551 | 6633 |
* Other size can be produced follow client's requirements. |
Features
1. High-performance rubber material: Yokohama Rubber Fenders are made of premium-quality rubber material, which is durable, resilient, and resistant to extreme weather conditions, UV radiation, and chemicals.
2. Advanced design: The fenders are designed with advanced technology to provide optimal protection to the ship during berthing. They are manufactured in various shapes and sizes to suit different applications and vessel types.
3. Excellent energy absorption: Yokohama Rubber Fenders are designed to absorb the kinetic energy of a ship during berthing through a combination of deformation and compression. They distribute the impact energy evenly, reducing the risk of damage to the ship and the dock infrastructure.
4. Easy to install and maintain: The fenders are easy to install and require minimal maintenance. They can be installed quickly and easily and can be replaced individually if needed.
5. Cost-effective: Yokohama Rubber Fenders are an affordable solution for ensuring safe and efficient port operations. They provide long-lasting protection to ships and docks, reducing the cost of repairs and downtime.
6. Superior quality assurance: Yokohama Rubber Fenders are manufactured to the highest quality standards and are extensively tested before delivery to ensure reliability and performance.
Applications
● Berthing protection
● Coastal protection
● Offshore applications
● Floating barriers
● Mooring operations
Advantages
◆ High Energy Absorption: Yokohama Rubber Fenders are designed to absorb high levels of energy when a vessel collides with them, which helps to minimize the risk of damage to the dock structure, ship, or cargo.
◆ Wide Range of Applications: They can be used for various applications such as berthing protection, mooring operations, floating barriers, offshore applications, and coastal protection, either in large or small ports.
◆ Easy Installation and Maintenance: Unlike other fendering systems, Yokohama Rubber Fenders are easy to install and require minimal maintenance. The modular design enables fast installation and easy replacement with minimal downtime.
◆ Durable and Long-lasting: Yokohama Rubber Fenders are made of high-quality materials and manufactured to strict quality standards. They are highly durable, resistant to wear, and can withstand extreme weather conditions and UV radiation.
◆ Cost-effective: Yokohama Rubber Fenders are cost-effective in the long run, as they help to reduce maintenance and repair costs. They are also an affordable alternative to other types of fenders and docking systems.
◆ Customizable: They are available in different sizes, shapes, and grades of rubber, allowing them to be customized to suit different applications, vessel types, and operating conditions.
