Ship Wharf High Quality Yokohama Rubber Fender Dock Protection Pneumatic Inflatable Marine
Description
Yokohama rubber fenders are a type of marine fender that is commonly used to protect ships and other vessels from damage during berthing and mooring operations. They are made from high-quality rubber materials and are designed to absorb the impact of a vessel as it comes into contact with a dock or pier. Yokohama fenders come in a variety of sizes and shapes to suit different types of vessels and docking configurations. They are widely used in ports and harbors around the world.
Yokohama fenders are high-quality marine fenders made by DockFender Group. They are designed to protect boats, ships, and other marine structures from damage caused by impacts with docks, piers, and other vessels. Yokohama fenders are made from high-strength rubber and are available in a variety of sizes and shapes to suit different applications. They are widely used in ports and harbors around the world and are known for their durability and reliability.
Specifications
Place of Origin | China |
Brand Name | DockFender |
Model Number | DF-3.3*6.5M |
Product Name | Ship Wharf High Quality Yokohama Rubber Fender Dock Protection Pneumatic Inflatable Marine |
Color | As required |
Material | Natural Rubber |
Thickness | 33 Layers |
Size | Customizable size |
Usage | STS, Dock, Quay, Port, LNG, Oil Tanker |
Certificate | ISO9001-2008 BV CCS CCC |
Packing | PP woven bags packed or customized |
Keywords | Yokohama Fender / Yokohama Rubber Fender |
Diameter x Length [mm] |
50kPa Performance Data |
80kPa Performance Data |
||||
Hull Pressure at GEA / kN / m2 |
Reaction Force / kN |
Energy Absorption / kNm |
Hull Pressure at GEA / kN / m2 |
Reaction Force / kN |
Energy Absorption / kNm |
|
1000 x 1500 | 122 | 182 | 32 | 160 | 239 | 45 |
1000 x 2000 | 132 | 257 | 45 | 174 | 338 | 63 |
1200 x 2000 | 126 | 297 | 63 | 166 | 390 | 88 |
1350 x 2500 | 130 | 427 | 102 | 170 | 561 | 142 |
1500 x 3000 | 153 | 579 | 153 | 174 | 761 | 214 |
1700 x 3000 | 128 | 639 | 191 | 168 | 840 | 267 |
2000 x 3500 | 128 | 875 | 308 | 168 | 1150 | 430 |
2500 x 4000 | 137 | 1381 | 663 | 180 | 1815 | 925 |
2500 x 5500 | 148 | 2019 | 943 | 195 | 2653 | 1317 |
3300 x 4500 | 130 | 1884 | 1175 | 171 | 2476 | 1640 |
3300 x 6500 | 146 | 3015 | 1814 | 191 | 3961 | 2532 |
3300 x 10600 | 158 | 5257 | 3067 | 208 | 6907 | 4281 |
4500 x 9000 | 146 | 5747 | 4752 | 192 | 7551 | 6633 |
* Other size can be produced follow client's requirements. |
Features
1. Easy to install and maintain.
2. Low reaction and hull pressure.
3. More suitable for small and large tidal ranges.
4. Lower maintenance cost.
Applications
1.Oil and gas tankers.
2.Fast ferries and aluminium vessels.
3.LPG vessels, ocean platforms, large docks.
4.Harbors and wharfs.
Advantages
1. Large compression deformation, low reaction force, high energy absorption.
2. Good floating performance, meet the needs of water level change.
3. With compressed air as medium, the collision energy consumption bu compressed air power.
4. Easy installation and long service life.
