Black Color Floating Foam Fender Marine Ocean Guard Buoy Dock Safety Boat Ships

1 Piece
MOQ
$5-$120
Price
Black Color Floating Foam Fender Marine Ocean Guard Buoy Dock Safety Boat Ships
Features Gallery Product Description Chat Now
Features
Specifications
Product Name: Black Color Marine Foam Fender Ocean Guard Buoy Floating Dock Safety Boat Ships
Model Number: DF-1500mm*3000mm
Material: EVA Closed Cell Foam, Polyurethane
Diameter: 300mm-4500mm
Length: 500mm-9000mm
Processing Service: Moulding
Color: Black, Orange, Yellow Etc.
Design: Customs Drawing
Standard: ISO 9001
Warranty: 2 Years
Highlight:

moulding floating foam fender

,

black color floating foam fender

,

1.5x3m foam fenders marine

Basic Infomation
Place of Origin: CHINA
Brand Name: DockFender
Certification: BV, DNV, ABS, SGS
Model Number: DF-1500mm*3000mm
Payment & Shipping Terms
Packaging Details: Wooden pallets and wooden cases
Delivery Time: 6 Work Days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 2600 PCS Per Month
Product Description

Black Color Marine Foam Fender Ocean Guard Buoy Floating Dock Safety Boat Ships



Description



The Floating EVA Foam filled fender is filled with high density foam. Nowadays, they are widely used in docks, ships, boats and vessels. High energy-absorption, corrosion resistance as well as anti-tearing. They can protect the docks and all the ships well when stopped.



Floating Foam Fender is available in diameters from 500 mm to 4,500 mm and lengths from 800 mm to 10,600 mm, different foam hardness grades as well as special shapes and sizes. The fenders could be installed with a two or four point mounting system, depending on the application. Standard colors are black and orange, individual skin colors available upon request.



Specifications



Product Name Black Color Marine Foam Fender Ocean Guard Buoy Floating Dock Safety Boat Ships
Brand Name DockFender
Model Number DF-1500mm*3000mm
Material Polyurethane, EVA, etc
Reaction Force 54kN to 7353kN
Energy Absorption 3.8KN-M to 7720KN-M
Standard ISO 9001, ISO 14001
Processing Service Moulding, Cutting
Lifespan 15-20 Years
Service OEM or ODM
Color Customers' Requirements
Application Port, Dock, Quay, etc



Black Color Floating Foam Fender Marine Ocean Guard Buoy Dock Safety Boat Ships 0



Diameter x Length Energy absorption at 60% comp Reaction force at 60% comp Approx. weight
(mm) (kNm) (kN) (kg)
300 x 1000 3.8 54 11
500 x 1000 10.6 91 41
600 x 1000 15.3 109 49
600 x 1000 18.3 131 55
700 x 1500 31 191 85
750 x 1500 36 204 89
900 x 1800 62 294 140
1000 x 1500 64 272 125
1000 x 2000 85 363 170
1200 x 2000 122 436 275
1200 x 2400 146 523 365
1250 x 2000 132 454 353
1250 x 2500 165 567 410
1500 x 3000 286 817 570
1500 x 4000 381 1089 720
1700 x 3000 367 926 700
1700 x 3500 428 1080 780
1800 x 3000 412 980 850
1800 x 3600 494 1176 965
2000 x 3000 508 1089 965
2000 x 3500 593 1271 1100
2000 x 4000 678 1452 1220
2400 x 4000 976 1743 1720
2400 x 4800 1171 2091 2140
2500 x 4000 1059 1815 1865
2500 x 5000 1324 2269 2500
2500 x 5500 1456 2496 2675
2700 x 5400 1668 2647 2865
3000 x 5000 1925 2750 3200
3000 x 6000 2287 3268 3740
3300 x 6500 2998 3894 4735
3600 x 7200 3953 4706 5800
4000 x 8000 4522 5809 8700
4200 x 8400 6277 6405 10000
4500 x 9000 7720 7353 10700


Features



1. Easy to install and maintain.
2. Low reaction force and high energy absorption.
3. Heavy-duty, unsinkable, impact-resistant.
4. Available colors.



Applications



● Oil & Gas Terminals

● Ship-to-ship operations

● Ship-to-shore operations

● Navy vessel berths and cruise terminals



Structure



Foam Core - The closed cell EVA foam core used inside offers unsink ability during operation.



Outer Rubber + Nylon Cord Fabrics - Specifically designed to seal EVA foam inside and to prevent any leakage.



Polyurea Spraying Coating - Permanent spray on coatings that protect the surface of fender body. It is more durable than rubber and flexible in all weather conditions; no softening in heat or becoming brittle in cold.



Black Color Floating Foam Fender Marine Ocean Guard Buoy Dock Safety Boat Ships 1



Black Color Floating Foam Fender Marine Ocean Guard Buoy Dock Safety Boat Ships 2

Black Color Floating Foam Fender Marine Ocean Guard Buoy Dock Safety Boat Ships 3Black Color Floating Foam Fender Marine Ocean Guard Buoy Dock Safety Boat Ships 4
