Name: 3.0m Jumbo Fender Superior Shock Absorption Saltwater Proof Cost Effective
Brand: Hongruntong Marine Co., Ltd.
SKU: HM-PRF15
Price: 910.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: Pneumatic Rubber Fender

Pressure: 50kPa, 80kPa

Color: Black Or Customized

Size: Customized

Accessories: Tyres, Steel Chain, Hang Ring

Standard: ISO17357-1:2014, PIANC2002

Service Life: 10~15 Years

Usage: Protect Boat

Basic Infomation

Place of Origin: China

Brand Name: Hongruntong Marine

Certification: ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS

Model Number: HM-PRF15

Payment & Shipping Terms

Packaging Details: Pallet, Wooden Box

Delivery Time: 10-20 Days

Payment Terms: T/T, L/C, D/A, , D/P, Western Union, MoneyGram

Supply Ability: 6870 Pcs/Month

Gallery

3.0m Jumbo Fender Superior Shock Absorption Saltwater Proof Cost Effective

Product Description

3.0m Jumbo Fender Superior Shock Absorption Saltwater Proof Cost Effective

Description

Engineered for high-energy impacts, our pneumatic fenders absorb 500–1500kJ of energy while resisting abrasion, oils, and extreme weather. The multi-ply rubber construction ensures long-term performance in -30°C to +70°C temperatures. With sizes from 1.5m to 4.0m, they are widely used in oil terminals, LNG carriers, and heavy-load docks. Features include anti-slip surfaces, corrosion-proof fittings, and low-maintenance design. ABS/LR/CE certified for global compliance.

Specifications

Place of Origin	China
Brand Name	Pneumatic Rubber Fender
Material	Natural Rubber
Color	Black
Application	In Ports with Extreme Tidal Variations Ship-to-Ship Lightering Operations Oil Gas (Typically Fsru) Temporary Berthing
Feature	Heat Resistance
Sample	Usually Free
Production Method	Moulding
Temperature	-40℃~300℃
Packing	Pallets
Lead time	7-14 days

Diameter x Length [mm]	50kPa Performance Data			80kPa Performance Data
Diameter x Length [mm]	Hull Pressure at GEA / kN / m2	Reaction Force / kN	Energy Absorption / kNm	Hull Pressure at GEA / kN / m2	Reaction Force / kN	Energy Absorption / kNm
1000 x 1500	122	182	32	160	239	45
1000 x 2000	132	257	45	174	338	63
1200 x 2000	126	297	63	166	390	88
1350 x 2500	130	427	102	170	561	142
1500 x 3000	153	579	153	174	761	214
1700 x 3000	128	639	191	168	840	267
2000 x 3500	128	875	308	168	1150	430
2500 x 4000	137	1381	663	180	1815	925
2500 x 5500	148	2019	943	195	2653	1317
3300 x 4500	130	1884	1175	171	2476	1640
3300 x 6500	146	3015	1814	191	3961	2532
3300 x 10600	158	5257	3067	208	6907	4281
4500 x 9000	146	5747	4752	192	7551	6633
* Other size can be produced follow client's requirements.

3.0m Jumbo Fender Superior Shock Absorption Saltwater Proof Cost Effective 0

Features

Dynamic Response Optimization

Computer-tuned air spring characteristics to dampen impacts up to 2.5m/s approach velocity (validated by LS-DYNA simulations).

Thermal Management

Phase-change material layers maintaining consistent internal pressure (±3%) across -20°C to 50°C operational range.

Abrasion Resistant Armor

12mm thick sacrificial wear layer with Kevlar® fiber reinforcement (DIN 53516 wear rate <0.08cm³).

High Energy Absorption, Low Reaction Force

Absorbs impact efficiently while minimizing hull stress — ideal for large vessel berthing.

Applications

• Fast ferry terminals

• Tugboat operations

• Military landing zones

• Ice-class vessel moorings

Advantages

Real Time Impact Tracking

Embedded IoT sensors (500Hz sampling) monitor pressure, strain, and impact forces for predictive maintenance.

AI Powered Analytics

Machine learning predicts wear patterns with 85% accuracy, reducing unplanned downtime by 40%.

Wireless Data Transmission

LoRaWAN connectivity (5km range) enables remote monitoring via cloud platforms.

Modular Repair Design

Damaged sections can be replaced individually, cutting repair costs by 30% vs. full-unit replacement.

FAQ

1. Q1: How long does the battery last?
A: 5+ years with inductive charging (IP68-rated), maintenance-free.

2. Q2: Can the system integrate with port management software?
A: Yes, supports API integration with most smart port systems.

3. Q3: What happens if a sensor fails?
A: Redundant sensors ensure continuous operation; alerts notify maintenance teams immediately.

4. Q4: Is the data secure?
A: Yes, AES-256 encrypted with optional private server hosting.

3.0m Jumbo Fender Superior Shock Absorption Saltwater Proof Cost Effective 1
