Name: Resistant To UV Radiation Jumbo Fender Customizable Dimensions Long Lifespan
Brand: Hongruntong Marine Co., Ltd.
SKU: HM-PRF02
Price: 79.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: Pneumatic Rubber Fender

Material: NR

Standard: ISO17357-1:2014, PIANC2002

Service Life: 10~15 Years

Color: Black Or Customized

Size: Customized

Usage: Protect Boat

Feature: Flexible Operation

Pressure: 50kPa, 80kPa

Highlight:

Long Lifespan Jumbo Fender

Customizable Jumbo Fender

Resistant UV Radiation Jumbo Fender

Basic Infomation

Place of Origin: China

Brand Name: Hongruntong Marine

Certification: ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS

Model Number: HM-PRF02

Payment & Shipping Terms

Packaging Details: Pallet, Wooden Box

Delivery Time: 10-20 Days

Payment Terms: T/T, L/C, D/A, , D/P, Western Union, MoneyGram

Supply Ability: 2080 Pcs/Month

Gallery

Resistant To UV Radiation Jumbo Fender Customizable Dimensions Long Lifespan

Product Description

Resistant To UV Radiation Jumbo Fender With Customizable Dimensions And Long Lifespan

Description

Pneumatic rubber fenders, also known as Yokohama fenders, are widely used in the maritime industry to prevent damage during ship docking and berthing operations. Constructed with reinforced rubber layers and filled with compressed air, they offer excellent shock absorption, reducing impact forces between vessels or between a vessel and the dock. Their flexible design allows them to adapt to different ship sizes and operating conditions. These fenders are corrosion-resistant, making them ideal for long-term use in harsh marine environments. With outstanding stability and self-floating characteristics, pneumatic rubber fenders are a trusted solution for ensuring safe and efficient port operations.

Resistant To UV Radiation Jumbo Fender Customizable Dimensions Long Lifespan 0

Specifications

Place of Origin	China
Brand Name	Pneumatic Rubber Fender
Material	Natural Rubber
Color	Black
Application	In ports with extreme tidal variations Ship-to-ship lightering operations Oil Gas (typically FSRU) Temporary berthing
Feature	Heat Resistance
Sample	Usually free
Production Method	Moulding
Temperature	-40℃~300℃
Packing	Pallets
Lead time	7-14 days

Diameter x Length [mm]	50kPa Performance Data			80kPa Performance Data
Diameter x Length [mm]	Hull Pressure at GEA / kN / m2	Reaction Force / kN	Energy Absorption / kNm	Hull Pressure at GEA / kN / m2	Reaction Force / kN	Energy Absorption / kNm
1000 x 1500	122	182	32	160	239	45
1000 x 2000	132	257	45	174	338	63
1200 x 2000	126	297	63	166	390	88
1350 x 2500	130	427	102	170	561	142
1500 x 3000	153	579	153	174	761	214
1700 x 3000	128	639	191	168	840	267
2000 x 3500	128	875	308	168	1150	430
2500 x 4000	137	1381	663	180	1815	925
2500 x 5500	148	2019	943	195	2653	1317
3300 x 4500	130	1884	1175	171	2476	1640
3300 x 6500	146	3015	1814	191	3961	2532
3300 x 10600	158	5257	3067	208	6907	4281
4500 x 9000	146	5747	4752	192	7551	6633
* Other size can be produced follow client's requirements.

Features

Long Service Life
Constructed from high-quality materials with excellent resistance to aging and environmental stress, pneumatic fenders offer an extended operational lifespan.

Cost Effective Maintenance
With minimal maintenance requirements, these fenders provide a long-term, low-cost solution for vessel and port protection.

Excellent Performance in Harsh Conditions
Designed to withstand high winds, strong currents, and extreme weather, ensuring reliable operation in demanding marine environments.

High Pressure Resistance
Engineered to endure significant pressure changes without compromising performance, making them ideal for large vessel applications.

Applications

● Barge and Tugboat Operations

● Ship Repair and Maintenance Areas

● Floating Bridges and Caissons

● Chemical and LNG Terminal Operations

Advantages

Versatile Applications
Suitable for ship-to-ship (STS), ship-to-dock (STD), and offshore platform applications, making them ideal for various marine operations.

Easy Installation and Relocation
Lightweight and portable, our fenders can be quickly deployed, repositioned, or stored without the need for heavy lifting equipment.

Long Service Life
Engineered for durability, our fenders offer an extended operational lifespan, reducing the need for frequent replacements.

Minimal Maintenance Required
Designed for long-term use with minimal upkeep, our fenders offer a cost-effective solution for port and vessel protection.

Resistant To UV Radiation Jumbo Fender Customizable Dimensions Long Lifespan 2

FAQ

1. How do you install a pneumatic rubber fender?
They can be hung using chains, shackles, and ropes, either between ships or along docks, depending on the application.

2. Do pneumatic rubber fenders require maintenance?
They require minimal maintenance, mainly periodic pressure checks, visual inspections, and cleaning to remove debris and marine growth.

3. What is the working pressure of a pneumatic rubber fender?
The standard pressure is either 50 kPa (low-pressure) or 80 kPa (high-pressure), depending on the application and customer requirements.

4. What happens if a pneumatic rubber fender gets punctured?
If punctured, the fender may lose air and require repair. Small damages can be patched, while severe damage may require replacement.
