1200mm X 2000mm Baby Fenders Robust Against Punctures Lightweight For Easy Deployment

1
MOQ
USD20-USD1800
Price
1200mm X 2000mm Baby Fenders Robust Against Punctures Lightweight For Easy Deployment
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Pneumatic Rubber Fender
Standard: ISO17357-1:2014, PIANC2002
Pressure: 50kPa, 80kPa
Color: Black Or Customized
Accessories: Tyres, Steel Chain, Hang Ring
Size: Customized
Service Life: 10~15 Years
Usage: Protect Boat
Highlight:

1200mm X 2000mm Baby Fenders

,

Lightweight Baby Fenders

,

Robust Against Punctures Baby Fenders

Basic Infomation
Place of Origin: China
Brand Name: Hongruntong Marine
Certification: ISO, BV, ABS, DNV, LR, SGS, CCS, RMRS
Model Number: HM-PRF641
Payment & Shipping Terms
Packaging Details: Pallet, Wooden Box
Delivery Time: 10-20 Days
Payment Terms: T/T, L/C, D/A, , D/P, Western Union, MoneyGram
Supply Ability: 6800 Pcs/Month
Product Description

1200mm X 2000mm Baby Fenders With Robust Against Punctures And Lightweight For Easy Deployment



Description



The pneumatic rubber fender is a high-performance marine fender designed to protect vessels during mooring, berthing, and ship-to-ship operations. It is made from multiple layers of strong rubber and reinforced with synthetic tire cords, ensuring superior durability and resistance to external pressure. The compressed air inside the fender acts as a cushion, absorbing kinetic energy while minimizing reaction forces on the hull. These fenders are highly versatile and suitable for a wide range of applications, including LNG carriers, bulk carriers, and naval ships. Their portability, easy deployment, and ability to function effectively in all weather conditions make them an indispensable asset for maritime safety.



1200mm X 2000mm Baby Fenders Robust Against Punctures Lightweight For Easy Deployment 01200mm X 2000mm Baby Fenders Robust Against Punctures Lightweight For Easy Deployment 1





Specifications



Place of Origin

China

Brand Name

Pneumatic Rubber Fender

Material

Natural Rubber

Color

Black

Application

In ports with extreme tidal variations

Ship-to-ship lightering operations

Oil Gas (typically FSRU)

Temporary berthing

Feature

Heat Resistance

Sample

Usually free

Production Method

Moulding

Temperature

-40℃~300℃

Packing

Pallets

Lead time

7-14 days



Diameter x Length
[mm]

50kPa
Performance Data

80kPa
Performance Data

Hull Pressure
at GEA
/ kN / m2

Reaction Force
/ kN

Energy Absorption
/ kNm

Hull Pressure
at GEA
/ kN / m2

Reaction Force
/ kN

Energy Absorption
/ kNm

1000 x 1500

122

182

32

160

239

45

1000 x 2000

132

257

45

174

338

63

1200 x 2000

126

297

63

166

390

88

1350 x 2500

130

427

102

170

561

142

1500 x 3000

153

579

153

174

761

214

1700 x 3000

128

639

191

168

840

267

2000 x 3500

128

875

308

168

1150

430

2500 x 4000

137

1381

663

180

1815

925

2500 x 5500

148

2019

943

195

2653

1317

3300 x 4500

130

1884

1175

171

2476

1640

3300 x 6500

146

3015

1814

191

3961

2532

3300 x 10600

158

5257

3067

208

6907

4281

4500 x 9000

146

5747

4752

192

7551

6633

* Other size can be produced follow client's requirements.





Features



Self Floating Design
The fender’s lightweight air-filled structure allows it to float freely on water without the need for additional buoyancy aids.



Adaptability to Tidal Variations
Pneumatic rubber fenders adjust automatically to changing water levels, maintaining optimal protection regardless of tide fluctuations.



Wide Range of Applications
Suitable for use in ports, harbors, offshore platforms, naval operations, and oil and gas terminals, providing versatility across industries.



Easy Installation and Relocation
Lightweight and flexible, these fenders can be easily deployed, repositioned, or stored as needed without requiring heavy machinery.





Applications



● Port and Harbor Operations



● Ship to Ship Transfer



● Offshore Oil and Gas Platforms



● Vessel Berthing at Cruise Terminals





Advantages



Low Reaction Force
The air-filled design keeps reaction forces low, reducing stress on vessel hulls and port facilities during berthing operations.



Strong and Durable Construction
With multiple reinforced layers, our fenders offer exceptional resistance to wear, pressure, and harsh marine conditions.



Corrosion and Weather Resistance
Our fenders are built to withstand seawater, UV radiation, ozone exposure, and extreme weather, ensuring long-term performance.



Self Floating Design
Pneumatic rubber fenders naturally float on water, adapting to tide levels and ensuring effective protection in all conditions.



1200mm X 2000mm Baby Fenders Robust Against Punctures Lightweight For Easy Deployment 2





FAQ



1. Do you offer customized fenders?
Yes, we provide customized sizes, pressure ratings, colors, and fittings based on customer specifications.



2. What is the difference between a chain & tire net type and a sling type fender?
Chain & tire net fenders have an additional protective net for enhanced durability, while sling-type fenders have no net and are lighter and easier to deploy.



3. Are pneumatic rubber fenders suitable for extreme weather conditions?
Yes, they are designed to withstand harsh weather, including strong winds, heavy waves, and temperature fluctuations.



4. How do you test the quality of pneumatic rubber fenders?
Our fenders undergo strict testing, including hydrostatic pressure tests, air-tightness tests, dimensional inspections, and performance evaluations.
