Yokohama Jumbo Fender with Sturdy Durable for Ship Protecting
Description
The Yokohama Rubber Fender is also commonly known as the Yokohama Pneumatic Fender, as it uses compressed air to absorb the impact of incoming vessels. This makes it highly effective at preventing damage to ship hulls and piers, as well as reducing the risk of injury to crew members.
The Yokohama Rubber Fender comes in diameters ranging from 500mm to 4500mm, which means it can be used on a wide variety of ships. It also comes with a range of accessories, including tyres, steel chains, and hang rings, which make it easy to install and use.
The Yokohama Rubber Fender is specifically designed for ship protection, and is ideal for use in ports, harbors, and offshore locations. Its high quality construction ensures that it can withstand even the harshest marine environments, and its durable rubber material provides excellent impact resistance.
Specifications
| Place of Origin |
China |
| Brand Name |
Yokohama Rubber Fender |
| Model Number |
HM-YRF41 |
| Material |
Natural Rubber |
| Color |
Black |
| Application |
In ports with extreme tidal variations
Ship-to-ship lightering operations
Oil Gas (typically FSRU)
Temporary berthing
|
| Feature |
Heat Resistance |
| Sample |
Usually free |
| Production Method |
Moulding |
| Temperature |
-40℃~300℃ |
| Packing |
Pallets |
| Lead time |
7-14 days |
Diameter x Length
[mm] |
50kPa
Performance Data |
80kPa
Performance Data |
Hull Pressure
at GEA
/ kN / m2 |
Reaction Force
/ kN |
Energy Absorption
/ kNm |
Hull Pressure
at GEA
/ kN / m2 |
Reaction Force
/ kN |
Energy Absorption
/ kNm |
| 1000 x 1500 |
122 |
182 |
32 |
160 |
239 |
45 |
| 1000 x 2000 |
132 |
257 |
45 |
174 |
338 |
63 |
| 1200 x 2000 |
126 |
297 |
63 |
166 |
390 |
88 |
| 1350 x 2500 |
130 |
427 |
102 |
170 |
561 |
142 |
| 1500 x 3000 |
153 |
579 |
153 |
174 |
761 |
214 |
| 1700 x 3000 |
128 |
639 |
191 |
168 |
840 |
267 |
| 2000 x 3500 |
128 |
875 |
308 |
168 |
1150 |
430 |
| 2500 x 4000 |
137 |
1381 |
663 |
180 |
1815 |
925 |
| 2500 x 5500 |
148 |
2019 |
943 |
195 |
2653 |
1317 |
| 3300 x 4500 |
130 |
1884 |
1175 |
171 |
2476 |
1640 |
| 3300 x 6500 |
146 |
3015 |
1814 |
191 |
3961 |
2532 |
| 3300 x 10600 |
158 |
5257 |
3067 |
208 |
6907 |
4281 |
| 4500 x 9000 |
146 |
5747 |
4752 |
192 |
7551 |
6633 |
| * Other size can be produced follow client's requirements. |
Features
Resistance to Harsh Environments
Constructed to withstand extreme temperatures, ultraviolet light, and harsh saltwater conditions.
Easy Maintenance
Requires minimal upkeep, allowing for cost-effective long-term use.
Custom Size Options
Available in a wide range of sizes to meet specific operational requirements and vessel types.
Integrated Inflation System
Some models feature integrated air chambers for adjustable buoyancy and impact protection.
Applications
● Cruise ship mooring
● Cargo vessel berthing
● Ferry terminals
Advantages
Robust R D Capabilities
Dedicated research and development to innovate and improve fender designs continuously.
Material Expertise
Comprehensive knowledge of selecting and using high-quality rubber and other materials.
Competitive Pricing
Cost-effective solutions without compromising on quality, providing great value to customers.
Strong Supply Chain Relationships
Established partnerships with reliable suppliers for consistent material availability.
FAQ
Q: What is the brand name of the rubber fender?
A: The brand name of the rubber fender is Hongruntong Marine.
Q: What is the model number of the rubber fender?
A: The model number of the rubber fender is HM-YRF41.
Q: Where is the rubber fender manufactured?
A: The rubber fender is manufactured in China.
Q: What are the dimensions of the rubber fender?
A: The dimensions of the rubber fender are 2.0 meters in diameter and 4.5 meters in length.
Q: What type of applications is the rubber fender suitable for?
A: The rubber fender is suitable for use in various marine environments, including ports, harbors, and docks.
